HDPE Polyethylene Pipe

Electrical, Power, Utility, & Telecommunications

HDPE Communication Duct is available in 3/4-inch to 6-inch diameters (8-inch and above available upon request) Sch 40, Sch 80, SDR 11, SDR 13.5 (other wall spec available upon request) with or without pull tape, in blue, green, black, orange, white, gray, terracotta and red. It comes in continuous reels and is available with internal lubrication and as parallel reeled.

Meets AWWA C901/C906, ASTM D2239, ASTM D2737, ASTM D3035, F714

UL 651A HDPE

  • Meets or exceeds the HDPE resin requirements per ASTM D 3350
  • UV Black (minimum carbon black loading of 2%)
  • Sequential footage markings
  • Permanent ink jet or indent print, tested and listed by Intertek Laboratories (ETL) to assure compliance with UL 651A
  • Certified by Dura-Line to comply with all UL 651A property and testing requirements

Smoothwall HDPE

  • Most common and popular HDPE duct
  • Smoothwall is available with an optional Silicore ULF permanently lubricated lining
  • These ducts perform well in all environments, aerial, direct buried and underground
  • Multiple wall thickness are available based on the application
UL 651A HDPE Table

Raceways' manufactured PVC and fiberglass sweeps meet all UL standards and are certified by ETL.
